Description

PACIFIC SCIENTIFIC 1903-15 Lightning Surge Arrestor - Maximum Duty, 10pF capacitance, 9.5-20 kV Impulse sparkover, 5,000 m operating altitude, antennas and tuning units

Part Number

1903-15

Price

Request Quote

Manufacturer

PACIFIC SCIENTIFIC

Lead Time

Request Quote

Category

Arrestors

Specifications

CAPACITANCE MAX, 1 MHZ

10 pF

DC SPARKOVER

7.5-8.0 kV

Extreme Duty Discharge

150 kA IT:220 AS I2T

IMPULSE SPARKOVER

9.5-20 kV

Insulation Resistance (U:50% DC sparkover)

10 exponent 9 O

OPERATING ALTITUDE, MAX

5,000 M

Shipping Weight

0.4 kg

Surge Life

100 kA (Mil-A-9094C) 12 strokes, 40 kA 8/20 µs 850 strokes, 10 kA 8/20 µs 2500

Temperature

Storage -65 to 95 C, Operating -55 to 70 C

Tightening Torque (top terminal nuts)

1 wrench 4.5 N-m (40 in-lb) max, 2 wrenches 6.0 N-m

Features

Ceramic Bushing
Line Connector
Metallic Housing

Datasheet

pacific scientific=1903 series=datashee-1515933059t.pdf

369 KiB

Download

Extracted Text

Pacific Scientific, EKD 6382 Rose Lane Carpinteria, CA 93013 PaCIFIC SCIEnTIFIC Cage 02101 Tel 805.576.5000 Fax 805.576.5020 www.psekd.com Electro Kinetics Division Data Sheet LIGHTNING SURGE ARRESTER, MAXIMUM DUTY 1903 SERIES Maximum lightning protection for LF-HF antennas and tuning units, for neutral-to-earth isolation in ac power protection schemes, and for protected ‘bridging’ of isolated ground zones and insulated pipe sections. DC SPARKOVER * MODEL CAPACITANCE IMPULSE SPARKOVER OPERATING NOMINAL MINIMUM NUMBER MAX, 1 MHz 10 kV/µs MAX 1 kV/ns ALTITUDE, MAX 200 V 170 V 1903-11 14 pF .85 kV 2.8 kV 15,000 m 250 V 210 V 1903-02 14 pF 1.0 kV 3.0 kV 15,000 m 275 V 230 V 1903-08 14 pF 1.1 kV 3.2 kV 15,000 m 300 V 250 V 1903-17 14 pF 1.2 kV 3.5 kV 15,000 m 500 V 420 V 1903-14 14 pF 2.0 kV 7.0 kV 15,000 m 700 V 600 V 1903-13 14 pF 2.5 kV 9.5 kV 15,000 m 750 V 675 V 1903-28 14 pF 2.5 kV 9.5 kV 15,000 m 1.25kV 1.0 kV 1903-18 12 pF 2.5 kV 8.5 kV 15,000 m 2.5 kV 2.0 kV 1903-19 10 pF 3.0 kV 6.0 kV 12,000 m 3.5 kV 3.0 kV 1903-26 10 pF 4.5 kV 8.5 kV 10,000 m 4.5 kV 4.0 kV 1903-05 10 pF 5.5 kV 9.5 kV 8,000 m 5.5 kV 5.0 kV 1903-27 10 pF 7.0 kV 14.0 kV 7,000 m 6.5 kV 6.0 kV 1903-07 10 pF 8.0 kV 19.0 kV 6,000 m 8.0 kV 7.5 kV 1903-15 10 pF 9.5 kV 20.0 kV 5,000 m 9.0 kV 8.0 kV 1903-22 10 pF 11.0 kV 22.0 kV 4,000 m 2 6 2 Extreme Duty Discharge - - - - 150 kA IT = 220 AS I T = 3 x 10 A s Surge Life - - - - - - 100 kA (Mil-A-9094C) 12 strokes 40 kA 8/20 µs 850 strokes 10 kA 8/20 µs 2500 strokes 9 Insulation Resistance (U = 50% DC sparkover) - - 10 Ω Temperature - - - - - Storage -65 to 95 C Operating -55 to 70 C Shipping Weight - - - - - 0.4 kg Tightening Torque (top terminal nuts) - - - 1 wrench 4.5 N-m (40 in-lb) max 2 wrenches 6.0 N-m (60 in-lb) max * DC sparkover is measured at <1 kV/s. In RF applications, the peak rf sparkover, as compared to the dc sparkover, will decrease approximately 7% at 1 MHz, 15% at 10 MHz, 20% at 20 MHz, 25% at 30 MHz. SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE TDS1903XX(g)
